| 材质 | 橡胶 | 使用温度 | -40-120（℃） |
| 适用范围 | 气缸 | 作用 | 气封 |
| 是否进口 | 是 | 品牌 | 日本阪上 |
| 型号 | 孔轴两用GLY | 样品或现货 | 现货 |
| 是否标准件 | 标准件 | 使用压力 | 20（MPa） |
| 性质 | 耐磨损、其他 |
/æ¥æ¬éªä¸/GLYåç¨å®è£
å¾.jpg)
/æ¥æ¬éªä¸/GLYè½´ç¨å®è£
å¾.jpg)
GLYパッキン寸法表
指示コードパッキンおよびみぞ寸法（単位：mm）標準
(RK701)耐熱用
(RF905)dDHGD1L
| *GLY-0010001K701 | 10 | 18 | 5 | 5.7 | 17.1 | 3 | 1.5 | |
| *GLY-0012001K701 | 12 | 20 | 5 | 5.7 | 19.1 | 3 | 1.5 | |
| *GLY-0014001K701 | 14 | 22 | 5 | 5.7 | 21.1 | 3 | 1.5 | |
| GLY-16 | 16 | 24 | 5 | 5.7 | 23.1 | 3 | 1.5 | |
| *GLY-0017001K701 | 17 | 25 | 5 | 5.7 | 24.1 | 3 | 1.5 | |
| GLY-18 | 18 | 26 | 5 | 5.7 | 25.1 | 3 | 1.5 | |
| GLY-20 | *GLY-20F | 20 | 28 | 5 | 5.7 | 27.1 | 3 | 1.5 |
| GLY-22.4 | *GLY-22.4F | 22.4 | 30 | 5 | 5.7 | 29.1 | 3 | 1.5 |
| GLY-25 | *GLY-25F | 25 | 33 | 5 | 5.7 | 32.1 | 3 | 1.5 |
| *GLY-0027001K701 | 27 | 35 | 5 | 5.7 | 34.1 | 3 | 1.5 | |
| GLY-28 | 28 | 36 | 5 | 5.7 | 35.1 | 3 | 1.5 | |
| GLY-30 | *GLY-30F | 30 | 40 | 6 | 7 | 39 | 3 | 3 |
| GLY-31.5 | 31.5 | 41.5 | 6 | 7 | 40.5 | 3 | 3 | |
| GLY-32 | 32 | 42 | 6 | 7 | 41 | 3 | 3 | |
| GLY-35 | *GLY-35F | 35 | 45 | 6 | 7 | 44 | 3 | 3 |
| *GLY-35.5 | 35.5 | 45.5 | 6 | 7 | 44.5 | 3 | 3 | |
| GLY-36 | *GLY-36F | 36 | 46 | 6 | 7 | 45 | 3 | 3 |
| GLY-40 | *GLY-40F | 40 | 50 | 6 | 7 | 49 | 3 | 3 |
| GLY-45 | *GLY-45F | 45 | 55 | 6 | 7 | 54 | 3 | 3 |
| GLY-50 | *GLY-50F | 50 | 60 | 6 | 7 | 59 | 3 | 3 |
| GLY-53 | *GLY-53F | 53 | 63 | 6 | 7 | 62 | 3 | 3 |
| *GLY-0055001K701 | 55 | 65 | 6 | 7 | 64 | 3 | 3 | |
| GLY-60 | *GLY-60F | 60 | 70 | 6 | 7 | 69 | 3 | 3 |
| *GLY-63 | 63 |
